Application:Applicableto various household appliances, LED lighting fixtures, electronic equipment,
lithium batteries, model airplanes, robots, model toys, etc.
AWG
Nominal
Structure of Conductor
Insulation
Overall
Conductor Resistance
Area (mm²)
No./mm
Thickness (mm)
Diameter (mm)
at 20℃Max Ω/km
26
128
7/0.16
0.760
1.80
150.00
24
0.205
12/0.15&7/0.20
0.760
2.05
94.20
22
0.324
18/0.15&7/0254
0.760
2.20
59.40
20
0.519
28/0.15&7/0.30
0.760
2.38
36.70
18
0.823
26/0.20&7/0.39
0.760
2.74
23.20
16
1.31
42/0.2&28/0.25&7/0.495
0.760
3.05
14.60
14
2.08
41/0.254&7/0.62
0.760
3.45
8.96
12
3.31
47/0.3&19/0.495
0.760
4.40
5.64
*Current ratings are based on a temperature rise of 40°C (single wire in free air).
