a)This series of inverters is a multi-functional,
low-noise voltage vector and V/F control.b)It realizes the fast response and precise control of
torque, and performs speed regulation action with extremely high control
precision, adding automatic tuning of motor parameters, automatic control and
torque control online switching, and torque tracking.c)Built-in PID controller, simple PLC, 17 kinds of fault
monitoring, rich I/O terminals and multiple speed setting methods can meet the
requirements of various loads for drive control.d)Standard MODBUS communication protocol. Easily realize
the communication between PLC, industrial computer and other industrial
equipment.
a)This series of inverters is a multi-functional, low-noise voltage vector and V/F control.
b)It realizes the fast response and precise control of torque, and performs speed regulation action with extremely high control precision, adding automatic tuning of motor parameters, automatic control and torque control online switching, and torque tracking.
c)Built-in PID controller, simple PLC, 17 kinds of fault monitoring, rich I/O terminals and multiple speed setting methods can meet the requirements of various loads for drive control.
d)Standard MODBUS communication protocol. Easily realize the communication between PLC, industrial computer and other industrial equipment.
Model
PowerSupply CapacityKVA
Voltage V
InputCurrent A
OutputCurrent A
AdaptableMotor
OverallDimension (L*D*H/MM)
PackingDimension (L*D*H/MM)
GrossWeight(KG)
KW
HP
SIT310-0.75S1
1.5
Single-phase power.220V,50/60Hz
8.2
4.0
0.75
1
142*85*116
210*110*165
1.35
SIT310-1.5S1
3.0
14.0
7.0
1.5
2
142*85*116
210*110*165
1.35
SIT310-2.2S1
4.0
23.0
9.6
2.2
3
142*85*116
210*110*165
1.35
SIT310-0.75G3
1.5
Three-phase power.380V,50/60Hz
3.4
2.1
0.75
1
142*85*116
210*110*165
1.35
SIT310-1.5G3
3.0
5.0
3.8
1.5
2
142*85*116
210*110*165
1.35
SIT310-2.2G3
4.0
5.8
5.1
2.2
3
142*85*116
210*110*165
1.35
SIT310-4.0G3
5.9
10.5
9.0
4.0
5
180*95*120
220*170*200
2.1
SIT310-5.5G3
8.9
14.6
13.0
5.5
7.5
180*95*120
220*170*200
2.1
SIT310-7.5G3
11.0
20.5
17.0
7.5
10
240*107*154
285*220*235
3.8
SIT310-11G3
17.0
26.0
25.0
11.0
15
240*107*154
285*220*235
3.8
Model
SIT310
Display
LED
Power
0.75-5.5KW
OEM
Accepted
Input voltage
AC 220V/ AC 380V
Warranty
18 months
Input frequency
50Hz/60Hz
Certification
CE
Output current
4-13A
Output waveform
Pure Sine Wave Output
Output frequency
0-500hz
Output Type
Triple, Multiple
Type
AC-DC-AC
Control Mode
VF control
Application industry
Textile equipment, ceramic equipment, water supply equipment, Printing Equipment, stone equipment, food equipment, fan equipment,
Conveyor belt equipment, woodworking equipment, industrial washing machine, ect.
