5 mA 5 V DC via bus connector at state off) 0 mA 24 V DC via bus connector at state off) 15 mA 5 V DC via bus connector at state on) 20 mA 24 V DC via bus connector at state on)
Response time
450 µs (turn-on) 450 µs (turn-off)
Maximum leakage current
0.1 mA transistor output
Maximum voltage drop
<0.4 V
Maximum tungsten load
<3 W transistor output
Local signalling
for output status 1 LED per channel (green)
Electrical connection
10 x 1.5 mm² removable screw terminal block pitch 3.81 mm for outputs
Maximum cable distance between devices
Unshielded cable <98.4 ft (30 m) transistor output
Insulation
Non-insulated between outputs Between output and internal logic AC
Marking
CE
Mounting support
Top hat type TH35-15 rail IEC 60715 Top hat type TH35-7.5 rail IEC 60715 plate or panel with fixing kit
Height
3.5 in (90 mm)
Depth
3.3 in (84.6 mm)
Width
1.08 in (27.4 mm)
Product Weight
0.24 lb(US) (0.11 kg)
Environment
Standards
IEC 61131-2
Product Certifications
cULus CE UKCA RCM EAC cULus HazLoc
Resistance to electrostatic discharge
8 kV in air IEC 61000-4-2 4 kV on contact IEC 61000-4-2
